POWER
On Device power on
Off Device power off
2.4G
On
The 2.4GHz Wi-Fi is activated.
Flash Device is transmitting data wirelessly over 2.4GHz.
Off The 2.4GHz Wi-Fi is disabled.
5G
On The 5GHz Wi-Fi is activated.
Flash Device is transmitting data wirelessly over 5.8GHz.
Off The 5GHz Wi-Fi is disabled.
WPS
Flash
WPS is
triggered
Off WPS is connected or disable
LAN1-4
On Link is established.
Flash Packets are transmitting or receiving.
Off LAN port is not connected.
WAN
On Link is established.
Flash Packets are transmitting or receiving.
Off WAN port is not connected.
USB
On USB connection is established.
Flash Data is being transmitted.
Off USB connection is not established.
Table 2-1-2-1 LED Indications
2.1.3
Rear Panel
The rear panel provides the physical connectors connected to the power adapter and any other network device.
Figure 2-1-3-1 shows the rear panel of the DIR-825M.
