5.2.5.3.
L2TPv3
This page is used to configure the parameters for Internet network which connects to peer by L2TPv3.
Figure 5-2-6-3-1 L2TPv3
Object Description
Local Host Address
The address of the LAN side device of local , eg:192.168.0.2
Remote Host Address
The address of the LAN side device of remote host ,
eg:192.168.8.2
Local Udp Port
Lan side device udp port.
Remote Udp Port
Remote device udp port
Tunnel Address
Wan interface ip address
Remote Tunnel Address
Remote device wan interface ip address
Tunnel Id
Local device tunnel id
Remote Tunnel Id
Remote device tunnel id
Session Id
Local device session id
Remote session Id
Remote device session id
MTU
You can keep the maximum transmission unit (MTU) as default.
