5.2.4
LAN
5.2.4.1.
IPv4
This page is used to configure the parameters for local area network which connects to the LAN port of your Access
Point. Here you may change the setting for IP address, subnet, DHCP, etc.
Figure 5-2-5-1-1 LAN IPv4
Object Description
LAN IP Address
Router’s LAN IP.
The default is 192.168.0.1. You can change it according to your
needs.
Subnet Mask
Router’s LAN subnet mask.
WORK MODE
If it is selected, the router serves as the DHCP server and
automatically assigns IP addresses to all computers in the LAN.
DHCP Client Range
Enter the start and end IP address of all the available successive
IPs.
Lease Time
Select the time for using one assigned IP from the dropdown list.
After the lease time, the AP automatically assigns new IP
addresses to all connected computers.
