D-Link DIR-830L User Manual

58D-Link DIR-830L User Manual
Section 3 - Conguration
Port Forwarding
Enter a name for the rule.
Enter the IP address of the computer on your local network that you
want to allow the incoming service to. Alternatively, select the device
from the drop-down menu.
Enter the TCP ports that you want to open. You can enter a single
port or a range of ports. Separate ports with a comma (for example:
24,1009,3000-4000).
Enter the UDP ports that you want to open. You can enter a single
port or a range of ports. Separate ports with a comma (for example:
24,1009,3000-4000).
Use the drop-down menu to select a schedule that the rule will
be enabled on. You can select Always Enable, or create your own
schedule in the Schedules section (refer to page 66).
Click Apply when you are done.
Name:
Local IP:
TCP Port:
UDP Port:
Schedule:
If you wish to remove a rule, click on its trash can icon in the Delete column. If you
wish to edit a rule, click on its pencil icon in the Edit column. If you wish to create a
new rule, click the Add Rule button.
Click Save when you are done.
Port forwarding allows you to specify a port or range of ports to open for specic devices on the network. This might be necessary for certain
applications to connect through the router. From the Advanced menu on the bar on the top of the page, click Port Forwarding.
After you click Add Rule, or if you click on the pencil icon to edit a rule, you will see
the screen to the right.
