D-Link DSL-224 User Manual

Section 2 – Installation
D-Link DSL-224 User Manual
6
Information you will need from your VDSL2(ADSL/ADSL2+) service provider
Username
This is the Username used to log on to your VDSL2(ADSL/ADSL2+) service provider’s network. Your VDSL2(ADSL/ADSL2+) service provider uses
this to identify your account.
Password
This is the Password used, in conjunction with the Username above, to log on to your VDSL2(ADSL/ADSL2+) service provider’s network. This is
used to verify the identity of your account.
WAN Setting / Connection Type
These settings describe the method your VDSL2(ADSL/ADSL2+) service provider uses to transport data between the Internet and your computer.
Most users will use
the default settings. You may need to specify one of the following WAN Setting and Connection Type configurations (Connection Type settings listed
in parenthesis):
 PPPoE/PPPoA (PPPoE LLC, PPPoA LLC or PPPoA VC-Mux)
 Bridge Mode (1483 Bridged IP LLC or 1483 Bridged IP VC Mux)
 IPoA/MER (Static IP Address) (Bridged IP LLC, 1483 Bridged IP VC Mux, 1483 Routed IP LLC, 1483 Routed IP VC-Mux or IPoA)
 MER (Dynamic IP Address) (1483 Bridged IP LLC or 1483 Bridged IP VC-Mux)
Modulation Type
VDSL2(ADSL/ADSL2+) uses various standardized modulation techniques to transmit data over the allotted signal frequencies. Some users may need
to change the type of modulation used for their service. The default DSL modulation used for the Router automatically detects all types of
VDSL2(ADSL/ADSL2+) modulation.
Security Protocol
This is the method your VDSL2(ADSL/ADSL2+) service provider will use to verify your Username and Password when you log on to their
network. Your Router supports the PAP and CHAP protocols.

D-Link DSL-224 Specifications

General

Flash memory	8 MB
Certification	CE, RoHS
Internal memory	32 MB
Built-in processor	Yes
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
SIM card slot	No
WAN connection type	RJ-11
VPN support	IPSec/PPTP/L2TP/PPPoE
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Mac operating systems supported	Mac OS X 10.4 Tiger
Windows operating systems supported	Windows 7, Windows 8, Windows Vista, Windows XP
Security algorithms	WDS, WEP, WMM, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	2 dBi
Power source type	AC
Product type	Tabletop router
Product color	White
LED indicators	DSL, LAN, Power, WAN, WLAN, WPS
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	100 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s

Weight and Dimensions

Depth	26 mm
Width	172 mm
Height	114 mm
