DSL-2750U Wireless ADSL2+ Router with 3G/LTE/Ethernet WAN Support
and USB Port
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
Protocol A protocol that the route will use.
Interface
From the drop-down list, select an interface through which the
destination network can be accessed. If you have selected the Auto
value, the router itself sets the interface on the basis of data on
connected networks.
Destination network
A destination network to which this route is assigned. You can specify
an IPv4 or IPv6 address.
You can specify an IPv6 address (2001:db8:1234::1) or an IPv6
address with a prefix (2001:db8:1234::/64).
Destination netmask
For IPv4 protocol only.
The destination network mask.
Gateway
An IP address through which the destination network can be accessed.
Metric
A metric for the route. The lower the value, the higher is the route
priority. Optional.
After specifying the needed parameters, click the SAVE button.
To edit an existing route, select a relevant line of the table. On the opened page, change the needed
parameters and click the SAVE button.
To remove an existing route, select the checkbox located to the left of the relevant line in the table
and click the DELETE button.
Page 165 of 210
