D-Link DSL-2750U User Manual

DSL-2750U Wireless ADSL2+ Router with 3G/LTE/Ethernet WAN Support
and USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
Inform settings
Enable
Move the switch to the right so the router may send reports (data on
the device and network statistics) to the ACS.
Interval Specify the time period (in seconds) between sending reports.
Auto Configuration Server Settings
URL address The URL address of the ACS provided by the ISP.
Username
The username to connect to the ACS.
Password
The password to connect to the ACS. Click the Show icon ( ) to
display the entered password.
Connection Request Settings
Username
The username used by the ACS to transfer a connection request to
the router.
Password
The password used by the ACS. Click the Show icon ( ) to
display the entered password.
Request port
The port used by the ACS. By default, the port 8999 is specified.
Request path
The path used by the ACS.
When you have configured the parameters, click the APPLY button.
Page 167 of 210

D-Link DSL-2750U Specifications

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Media Interface

ADSL interface connector type	RJ-11
ADSL interface cable type	24/26 AWG twisted pair telephone line
LAN interface port type	RJ-45
LAN interface standard	10/100BASE-T Ethernet
