D-Link N300 User Manual

DIR-620S Wireless N300 Router with 3G/LTE Support and
USB Port
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
Enabled
If the switch is moved to the right, the rule is active.
Move the switch to the left to disable the rule.
MAC address
In the field, enter the MAC address to which the rule will be
applied. You can enter the MAC address of a device connected to
the router's LAN at the moment. To do this, select the relevant
device from the drop-down list (the field will be filled in
automatically).
Upload
Maximum rate
Specify the maximum value of the upstream traffic rate (Mbps) or
move the Not limited switch to the right not to limit the maximum
bandwidth of upstream traffic.
Download
Maximum rate
Specify the maximum value of the downstream traffic rate (Mbps)
or move the Not limited switch to the right not to limit the
maximum bandwidth of downstream traffic.
After specifying the needed parameters, click the SAVE button.
To edit a rule, left-click the relevant rule. In the opened window, change the needed parameters and
click the SAVE button.
To remove a rule, select the checkbox located to the left of the relevant line in the table and click
the DELETE button ( ).
Page 137 of 236

D-Link N300 Specifications

General

Wireless Speed	300 Mbps
Frequency Band	2.4 GHz
Wireless Standards	IEEE 802.11n/g/b
Antenna Type	Internal
Ports	1 x 10/100 Mbps Ethernet Port
Security	WPA, WPA2
Product Type	Range Extender
