Configuring via Web-based Interface
IGMP
On the Advanced / IGMP page, you can allow the router to use IGMP.
IGMP is used for managing multicast traffic (transferring data to a group of destinations). This
protocol allows using network resources for some applications, e.g., for streaming video, more
efficiently.
Figure 150. The Advanced / IGMP page.
The following elements are available on the page:
Parameter Description
IGMP
Enable Move the switch to the right to enable IGMP.
IGMP version
Select a version of IGMP from the drop-down list.
Interface
From the drop-down list, select a connection of the Dynamic IPv4 or
Static IPv4 type for which you need to allow multicast traffic (e.g.
streaming video).
Set the address of
outgoing IGMP packets
equal to 0.0.0.0
Move the switch to the right if you want all outgoing IGMP packets
to have the IP address 0.0.0.0.
After specifying the needed parameters, click the APPLY button.
Page 185 of 236
