config ethernet_oam ports (mode)
Used to co
nfigure Ethernet OAM mode for ports.
Purpose
config eth
ernet_oam ports [ <portlist> | all ] mode [ active | passive ]
Syntax
The co
mmand is used to configure Ethernet OAM for ports to operate in active or passive
mode.
Description
Port configured in active mode:
(1) Initiate the exchange of Information OAMPDUs as defined by the discovery state diagram.
(2) Active port is permitted to send any OAMPDU while connected to a remote OAM peer
entity in active mode.
(3) Active port operates in a limited respect if the remote OAM entity is operating in passive
mode.
(4) Active port should not respond to OAM remote loopback commands and variable requests
from a passive peer.
Port configured in passive mode:
(1) Do not initiate the discovery process
(2) React to the initiation of the Discovery process by the remote. This eliminates the
possibility of passive-to-passive links.
(3) Shall not send Variable request or loopback Control OAMPDUs” for describe the active
and passive mode.
Not
e: When a port is OAM-enabled, changing the OAM mode will cause the
OAM discovery to be re-started
<po
rtlist> - Specifies a range of ports to be configured. Use all to specify all ports.
Parameters
mode - Specify to operate in either active mode or passive mode. The default mode is
active.
Only Administrator-level users
can issue this command.
Restrictions
Example usage:
To configure port 1 OAM mode to passive:
DES-3200-28F:4# config ethernet_oam ports 1 mode passive
Commands: config ethernet_oam ports 1 mode passive
Success
DES-3200-28F:4#
