77D-Link DAP-1522 User Manual
Section 4 - Security
It is recommended to enable encryption on your wireless access point before your wireless network adapters. Please
establish wireless connectivity before enabling encryption. Your wireless signal may degrade when enabling encryption
due to the added overhead.
1. Log into the web-based configuration by opening a web browser
and entering the IP address of the access point (192.168.0.50).
Click on Setup and then click Wireless Settings on the left
side.
2. Next to Security Mode in the Wireless Security Mode section,
select WPA-Enterprise.
3. Next to WPA Mode in the WPA section, select Auto (WPA or
WPA2), WPA2 Only, or WPA Only. Use Auto if you have wireless
clients using both WPA and WPA2.
4. Next to Cipher Type, select TKIP, AES, or TKIP and AES.
5. Next to Group Key Update Interval, enter the amount of time before the group key used for broadcast and multicast
data is changed.
6. Next to RADIUS Server IP Address in the EAP (802.1X) section, enter the IP Address of your RADIUS server.
7. Next to RADIUS Server Port, enter the port you are using with your RADIUS server. 1812 is the default port.
8. Next to RADIUS Server Shared Secret, enter the security key.
9. ClickClick Save Settings at the top of the window to save your settings..
Configure WPA-Enterprise (AP Mode)

D-Link xtreme n duo dap-1522 Specifications

Physical Interfaces

gigabit LAN ports	4
push-button for Wi-Fi Protected Setup	1
three-way switch	1

Weight and Dimensions

dimensions	4.4” x 5.7” x 1.3”
packaging dimensions	8.2” x 10.8” x 2.7”
weight	0.5 lbs
packaging weight	1.7 lbs
