Decreases the current parameter (if it is an editable parameter).
Increases the current parameter (if it is an editable parameter).
Holding down the “+” key or the “-” key allows the automatic increase/
decrease of the parameter selected. After the “+” key or the “-” key has
been held down for 3 seconds, the automatic increase/decrease speed
increases.
When the + key or the - key is pressed the selected value is
modied and saved immediately in the permanent memory (EE-
prom). If the machine is switched off, even accidentally, in this
phase it does not cause the loss of the parameter that has just
been set.
The SET key is only for leaving the current menu and is not nec-
essary for saving the changes made. Only in particular cases
described in chapter 0 are some values updated by pressing
“SET” or “MODE”.
Warning leds
• Power
White led. Lit with a xed light when the machine is powered.
Blinking when the machine is disabled (see par. 5.5).
• Alarm
Red led. Lit with a xed light when the machine is blocked by an
error.
• Communication
Blue led. Lit with a xed light when communication wireless is
used and is working correctly. It blinks with a slow frequency if,
Table 6: Key functions
when congured to work in communication mode, communication
is not available, is not detected, or there are problems. It blinks
with a high frequency during association with other wireless de-
vices. Off if communication is not used.
Menus
The complete structure of all the menus and of all the items of which they
are composed is shown in Table 9.
Access to the menus
The various menus can be accessed from the main menu in two ways:
1 - Direct access with a combination of keys
2 - Access by name with a drop-down menu
6.1 Direct Access with a Combination of Keys
The desired menu can be accessed directly by pressing simultaneously
the appropriate combination of keys for the required time (for example
MODE SET to enter the Setpoint menu) and the various items in the menu
are scrolled with the MODE key.
Table 7 shows the menus that can be reached with the combinations of
keys.
