Rear Wheel/Brake/Suspension
13. Rear Wheel/Brake/Suspension
13-1
Service Information 13-1
Troubleshooting 13-2
Rear Wheel 13-3
Rear Brake 13-4
Rear Cushion 13-6
Service Information
General Safety
● If the brake drum or lining is contaminated with oil, braking power will be lost. If contaminated with oil,
clean the brake drum, and replace the brake shoe.
Item Standard value Service limit
Axle shaft run out - 0.2(0.008)
Rear wheel rim runout
Radical - 2.0(0.08)
Axial - 2.0(0.08)
Rear brake drum inner diameter 116.0-116.3(4.56-4.57) 117(4.60)
Rear brake lining thickness 4.0(0.16) 2.0(0.08)
Rear cushion spring free length 245(9.63) 238(9.36)
Torque values:
Rear axle nut 6.0~8.0kg-m(60-80N.m, 43-58ft-lb)
Rear cushion upper bolt 2.7kg-m(27N.m, 20ft-lb)
Rear cushion lower bolt 4.0kg-m(40N.m, 29ft-lb)
Unit: mm(in)
Specifications
13
