Inspections/Adjustments
3-1
3. Inspections/Adjustments
Service Information 3-1
Regular Inspection Schedule 3-3
Fuel Line 3-4
Throttle Grip Operation 3-4
Air Cleaner 3-4
Spark Plug 3-5
Valve Tappet Clearance 3-5
Cylinder Compression Pressure
3-6
Carburetor Idling 3-6
Brake Fluid 3-7
Brake Pad/Shoe 3-7
Brake System 3-7
Brake Lever Free Play 3-8
Headlight Adjustment 3-8
Side Stand 3-8
Suspension 3-9
Bolts and Nuts 3-9
Wheels/Tires 3-10
Steering Head Bearing 3-10
Service Information
WARNING
● The exhaust gas contains poisonous substance. Do not keep engine idling in a closed or poorly ventilated
place for a long period of time.
NOTES
Driver only
Front tire 175kPa (1.75kg/㎠)
Rear tire 200kPa (2.00kg/㎠)
Cold tire pressure
Driver and
Front tire 225kPa (2.25kg/㎠)
a passenger
Rear tire 280kPa (2.80kg/㎠)
Tire size
Front tire 120/70-13(Tubeless)
Rear tire 130/60-13(Tubeless)
Min,tread depth
Front tire 4mm (0.16 in)
Rear tire 7.5mm (0.3 in)
For information on engine oil and oil filter, refer to sections 2-3 and 2-4
Stand the main stand prior to beginning work.
Throttle grip play 2–6mm(1/8-1/4 in)
Spark plug CR8EH-9
Spark plug gap 0.8–0.9mm(0.031-0.035in)
Valve clearance
IN 0.12± 0.02mm(0.005±0.001 in)
EX 0.12±0.02mm(0.005±0.001 in)
Carburetor idle speed 1,800±100rpm
Cylinder pressure 13.8kg/㎠
Specifications
Tires
3
