Page #190 background image
Light/Switch/Horn
18-7
TRUNK LAMP SWITCH
Trunk Lamp Switch
INSPECTION
●Release the seat lock with the main key, open the seat.
●Disconnect the trunk lamp switch, check for continuity
between the terminals.
TR/L BAT
BLACK RED
COLOR
TERMINAL
PUSH
FREE
Trunk Lamp Switch
