Service manual CP-785A
- 10 -
EW Trapez
3-3-7 - AGC
- Adjust the antenna signal level at 68 dBµV± 2 (UHF - CH25)
- Set RF AGC to 0.
- Increase RF AGC level and stop when the level on pin 6 of TDA936x goes below 2.5 Vdc
