Daewoo DTE-25G5THS User Manual

Electrical Parts List
loc part_cd part_nm part_desc remark
0000A 4857028214 HEAT SINK(for I301) AL EX
0000A 4857028215 HEAT SINK(for I602) AL EX
0000A 4857031100 HEAT SINK(for I901) A1050P-H24 T2.0
0000A 4857027609 HEAT SINK(for Q401) AL EX
00010 4850Q00810 BATTERY R6P/LN
00030 4859000160 CABLE SCART S-RCA 3P/DIN 4P(1.2M)
A001 4859804393 PCB MAIN 330X246
C101 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C102 CEXF1H470V C ELECTRO 50V RSS 47MF (6.3X11) TP
C103 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C104 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C106 CEXF1C221V C ELECTRO 16V RSS 220MF (8X11.5) TP
C108 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C110 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C120 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C121 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C305 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
C313 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C315 CEXF2C470C C ELECTRO 160V RUS 47MF (13X25) TP
C320 CBXF1H104Z C CERA SEMI 50V F 0.1MF Z (TAPPING)
C350 CCXF1H473Z C CERA 50V F 0.047MF Z (TAPPING)
C351 CCXF1H473Z C CERA 50V F 0.047MF Z (TAPPING)
C370 CMXM2A473J C MYLAR 100V 0.047MF J (TP)
C401 CEXF1H100C C ELECTRO 50V RUS 10MF (5X11) TP
C402 CMYH3C123J C MYLAR 1.6KV BUP 0.012MF J
29"
CMYH3C912J C MYLAR 1.6KV BUP 9100PF J
25"
C404 CMYH3C822J C MYLAR 1.6KV BUP 8200PF J
29"
CMYH3C752J C MYLAR 1.6KV BUP 7500PF J
25"
C408 CMYE2G624J C MYLAR 400V PU 0.62MF J
29"
CMYE2G434J C MYLAR 400V PU 0.43MF J
25"
C412 CEXF2C339C C ELECTRO 160V RUS 3.3MF (8X16) TP
C414 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C415 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C418 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
C420 CCXB2H222K C CERA 500V B 2200PF K (TAPPING)
C430 CMYH3C122J C MYLAR 1.6KV BUP 1200PF J
C431 CMXE2D103J C MYLAR 200V PU 0.01MF J (TP)
C440 CMXE2G273J C MYLAR 400V PU 0.027MF J (TP)
C499 CEYD1H689W C ELECTRO 50V RHD 6.8MF (16X35.5)
C500 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C501 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C502 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C509 CEXF1E470V C ELECTRO 25V RSS 47MF (5X11) TP
C511 CMXM2A224J C MYLAR 100V 0.22MF J
C512 CMXM2A224J C MYLAR 100V 0.22MF J
C513 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C514 CEXF1E101V C ELECTRO 25V RSS 100MF (6.3X11) TP
C515 CBZR1C222M C CERA 16V Y5R 2200PF M (AXIAL)
C516 CBZR1C472M C CERA 16V Y5R 4700PF M (AXIAL)
C517 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C518 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C519 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C520 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C521 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C523 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z
C524 CMXL1J104J C MYLAR 63V MEU 0.1MF J
C525 CCXB1H102K C CERA 50V B 1000PF K (TAPPING)
- 50 -
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
