Service manual CP-785A
- 2 -
1-1 Specifications
TV standard
PAL, SECAM - B/G, H
Sound system
NICAM B/G
FM 2Carrier B/G
Power consumption
25" : 113 W approx.
29" : 118 W approx.
Sound Output Power
25" : 5W x 5W (at 60% mod, 10%THD)
29" : 5W x 5W (at 60% mod, 10%THD)
Speaker
25" : 7W 8 ohm x 2
29" : 7W 8 ohm x 2
Teletext system
10 pages memory FASTEXT (FLOF or TOP)
Aerial input
75 ohm unbalanced
Channel coverage
Off-air channels, S-cable channels and hyperband
Tuning system
frequency synthesiser tuning system
Visual screen size
25" : 59 cm
29" : 68 cm
Channel indication
On Screen Display
Program Selection
100 programmes
Aux. terminal
INPUT1(SCART) : Audio / Video In, S-VHS In(with cable)
INPUT2(RCA) : Audio / Video In
OUTPUT(RCA) : TV OUT
Headphone jack (3.5 mm) on front of cabinet
Remote Control Unit
R-40A01 / R-44N08(RD-D90)
RCA Jack - input 2
Pin Signal Description Matching value
1 Video Input 1.0 Vpp+/- 3dB , Impedance 75 ohm
2 Audio Input Left
0.5 Vrms, Impedance > 10k ohm
3 Audio Input Right 0.5 Vrms, Impedence > 10k ohm
