Preset value Where used
Tank temperatures
under [5] Tank
Restriction: Only
applicable if a
DHW tank is
present.
[5.2] Comfort
setpoint
You can use these preset values in [5.5]
Schedule (weekly schedule screen for
the DHW tank) if the DHW tank mode is
one of the following:
▪ Schedule only
▪ Schedule + reheat
[5.3] Eco
setpoint
[5.4] Reheat
setpoint
The software uses this preset value if
the DHW tank mode is
Schedule + reheat.
Electricity prices
under [7.5] User
settings >
Electricity
price
Restriction: Only
applicable if
Bivalent is
enabled by the
installer.
[7.5.1] High You can use these preset values in
[7.5.4] Schedule (weekly schedule
screen for the energy prices).
See "5.8.4Setting the energy
prices"[444].
[7.5.2] Medium
[7.5.3] Low
Additional to the user-defined preset values, the system also contains some
system-defined preset values that you can use when programming schedules.
Example: In [7.4.2] User settings > Quiet > Schedule (weekly schedule for
when the unit has to use which quiet mode level), you can use the following
system-defined preset values: Quiet/More quiet/Most quiet.
5.8.2 Using and programming schedules
About schedules
Depending on your system layout and installer configuration, schedules for
multiple controls may be available.
You can… See…
Set if a specific control needs to act according
to a schedule.
"Activation screen" in "Using and
programming schedules"[437]
Select which schedule you currently want to use for a specific control. The system
contains some predefined schedules. You can:
Consult which schedule is currently
selected.
"Schedule/Control" in "Using and
programming schedules"[437]
Select another schedule if needed. "Using and programming
schedules"[437]
Program your own schedules if the
predefined schedules are not satisfactory.
The actions you can program are control
specific.
▪ "Possible actions" in "Using and
programming schedules
"[437]
▪ "5.8.3 Schedule screen:
Example"[440]

Daikin Altherma 3 M Specifications

General

Heating Capacity	4.0 - 16.0 kW
Cooling Capacity	3.5 - 14.0 kW
Refrigerant	R-32
Energy Efficiency Class	A+++
Operating Range (Heating)	-25°C to 35°C
Operating Range (Cooling)	10°C to 46°C
Type	Air to Water Heat Pump
Sound Power Level	58-65 dB(A) (depending on model)
