BRC1E52A7 Operation manual
4PW71265-1 – 10.2011
8
1. Operation mode selector button
• Press this button to select the operation
mode of your preference. (See page 21.)
* Available modes vary with the connecting
model.
2. Fan speed/Airow direction
setting button
• Used to indicate the Air Volume/Airow
direction setting screen. (See page 14.)
* Available fan speed and Airow direction
vary with the connecting model.
3. Menu/Enter button
• Used to indicate the main menu.
(See page 25 for the menu items.)
• Used to enter the setting item selected.
4. Up button (Be sure to press the
part with the symbol )
• Used to raise the set temperature.
• The next items on the upper side will be
highlighted.
(The highlighted items will be scrolled
continuously when the button is kept
pressed.)
• Used to change the item selected.
5. Down button (Be sure to press
the part with the symbol )
• Used to lower the set temperature.
• The next items on the lower side will be
highlighted.
(The highlighted items will be scrolled
continuously when the button is kept
pressed.)
• Used to change the item selected.
6. Right button (Be sure to press
the part with the symbol )
• Used to highlight the next items on the
right-hand side.
• Each screen is scrolled in the right-hand
direction.
7. Left button (Be sure to press
the part with the symbol )
• Used to highlight the next items on the
left-hand side.
• Each screen is scrolled in the left-hand
direction.
8. On/Off button
• Press this button and system will start.
• Press this button again and system will
stop.
9. Operation lamp (Green)
• This lamp lights up during operation.
• This lamp blinks if a error occurs.
10. Cancel button
• Used to return to the previous screen.
11. LCD (with backlight)
• The backlight will be light for approximately
30 seconds by pressing any operation
button. Operate buttons excluding the On/
Off button while the backlight is lit.
• If 2 remote controllers are used to control a
single indoor unit, the backlight of the
remote controller operated earlier than the
other one will be lit.
