Specification Data DAMA-SM-21-001
16 Specifications
1. Specification Data
Cooling Only
1) ALL UNITS ARE BEING TESTED ACCORDING TO AHRI 210/240 STANDARD.
2) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
MODEL
INDOOR UNIT FTK09A FTK12A
OUTDOOR UNIT RK09A RK12A
Rated Capacity (Min. ~ Max.)
kW 2.61 (1.30 - 3.00) 3.20 (1.30 - 3.90)
Btu/h 8900 (4400 - 10200) 10900 (4400 - 13300)
Moisture Removal gal/h 0.08 0.19
Rated Running Current A 3.36 3.99
Rated Power Consumption W 712 872
EER Btu/h/W 12.5
SEER 19.0
Power Factor (Rated) N/A
Piping
Connections
Liquid inch (mm) 1/4” (6.35)
Gas inch (mm) 3/8” (9.52)
Refrigerant
Type R410A
Charge lbs (kg) 1.54 (0.7) 2.09 (0.95)
Max. Interunit Piping Length ft (m) 65-5/8 (20)
Max. Interunit Height Difference ft (m) 49-1/4 (15)
Chargeless ft (m) 32-13/16 (10)
Amount of Additional Charge of Refrigerant oz/ft (g/m) 0.21 (20)
INDOOR UNIT FTK09A FTK12A
Front Panel Colour WHITE
Airflow Rate
Turbo CFM 466 473
High CFM 431 436
Medium CFM 322 316
Low CFM 249 247
Quiet CFM 142 132
Sound Pressure Level (H/M/L/Q) dBA 43/36/30/19 45/37/31/19
Fan
Type CROSS FLOW
Drive DIRECT
Speed 3 STEPS, QUIET, AUTO, TURBO
Fan Motor
Type DIRECT CURRENT
Motor Output W 38 38
Running Current (Rated) A 0.17 0.17
Power Consumption (Rated) W 53 53
Air Direction Control UP, DOWN, LEFT, RIGHT
Air Filter CATECHIN
Dimensions (H X W X D) inch (mm) 11-1/3 X 30-29/32 X 9-27/32 (288 X 785 X 250)
Packaged Dimensions (H X W X D) inch (mm) 13-7/8 X 32-3/4 X 12-3/8 (350 X 830 X 314)
Weight lbs (kg) 20 (9) 22 (10)
Gross Weight lbs (kg) 25 (11) 27 (12)
Condensate Drain Size in. (mm) 3/4 (19.00)
OUTDOOR UNIT RK09A RK12A
Casing Colour IVORY WHITE
Airflow Rate High CFM 1083 1051
Sound Pressure Level dBA 46 49
Fan
Type PROPELLER
Drive DIRECT
Fan Motor
Type DIRECT CURRENT
Index of protection (IP) 24
Insulation Grade E
Running Current (Rated) A 0.33 0.47
Power Consumption (Rated) W 32 43
Motor Output W 41
Poles 8
Compressor
Type HERMETIC SWING
Model M5SLY10/15FR-1
Oil type DAPHNE FVC50K
Oil amount oz (cm
3
) 12.4 (375)
Running Current (Rated) A 2.86 3.35
Power Consumption (Rated) W 627 776
Heat Exchanger Type FIN TUBE
Starting Current A 5.29 6.06
Dimensions (H X W X D) inch (mm) 21-11/16 X 26-1/2 X 11-3/16 (550 X 675 X 284)
Packaged Dimensions (H X W X D) inch (mm) 24-1/64 X 31-3/8 X 15-1/8 (610 X 801 X 384)
Weight lbs (kg) 55 (25) 62 (28)
Gross Weight lbs (kg) 62 (28) 68 (31)
Drawing No. 3D128372 3D128372
Document No. (Set) 3D128372 3D128372
COOLING
INDOOR: 80°FDB (26.7°CDB) / 67°FWB (19.4°CWB)
OUTDOOR: 95°FDB (35°CDB)
