Troubleshooting with LED DAMA-SM-21-001
55 Service Diagnosis
2. Troubleshooting with LED
2.1 Indoor Unit
Operation Lamp The operation lamp blinks when any of the following errors is detected.
1. A protection device of the indoor or outdoor unit is activated, or the thermistor malfunctions.
2. A signal transmission error occurs between the indoor and outdoor units.
In either case, conduct the diagnostic procedure described in the following pages.
2.2 Outdoor Unit
The outdoor unit has a green LED (LED A) on the PCB.
When the microcomputer works in order, the LED A blinks.
Refer to pages 111, 112 for the location of LED A
ON/OFF
switch
LED INDICATION LIGHTS
To Next Page
