IM 972-2 • MAVERICK I ROOFTOP SYSTEMS 24 www.DaikinApplied.com

Auxiliary Heater Kit Performance
Table 13: Auxiliary Heater Kits Characteristics and Application: 208/240V — 3 Phase
Unit Model Number
MPS
Heater Kit
Model No. RXJJ
Heater Kw @
208/240 V/3 Phase
Heater Kit Fla Unit Min. Ckt. Ampacity
Max. Fuse or Ckt. Bkr. Size
(Ckt. Bkr. Must Be HACR
Type For USA)
015 Low Static Drive
NONE — — 78/78 100/100
CE20C 14.4/19.2 40.0/46.2 78/78 100/100
CE40C 28.8/38.3 79.9/92.2 115/130 125/150
CE60C 43.2/57.5 119.9/138.3 165/188 175/200
CE75C 54/71.9 149.8/172.8 202/231 225/250
015 High Static Drive
NONE — — 81/81 100/100
CE20C 14.4/19.2 40.0/46.2 81/81 100/100
CE40C 28.8/38.3 79.9/92.2 119/134 125/150
CE60C 43.2/57.5 119.9/138.3 169/192 175/200
CE75C 54/71.9 149.8/172.8 206/235 225/250
020 Low Static Drive
NONE — — 101/101 125/125
CE20C 14.4/19.2 40.0/46.2 101/101 125/125
CE40C 28.8/38.3 79.9/92.2 119/134 125/150
CE60C 43.2/57.5 119.9/138.3 169/192 175/200
CE75C 54/71.9 149.8/172.8 206/235 225/250
020 High Static Drive
NONE — — 109/109 125/125
CE20C 14.4/19.2 40.0/46.2 109/109 125/125
CE40C 28.8/38.3 79.9/92.2 129/145 150/150
CE60C 43.2/57.5 119.9/138.3 179/202 200/225
CE75C 54/71.9 149.8/172.8 217/245 225/250
025 Low Static Drive
NONE — — 147/147 175/175
CE20C 14.4/19.2 40.0/46.2 147/147 175/175
CE40C 28.8/38.3 79.9/92.2 147/147 175/175
CE60C 43.2/57.5 119.9/138.3 181/204 200/225
CE75C 54/71.9 149.8/172.8 218/247 225/250
025 High Static Drive
NONE — — 149/149 175/175
CE20C 14.4/19.2 40.0/46.2 149/149 175/175
CE40C 28.8/38.3 79.9/92.2 149/151 175/175
CE60C 43.2/57.5 119.9/138.3 186/209 200/225
CE75C 54/71.9 149.8/172.8 223/252 225/300
