Indoor Unit: FTXS09/12LVJU SiUS091133
159 Removal Procedure
1.2 Removal of Front Panel
Procedure Warning Be sure to wait for 10 minutes or more after turning off all power supplies
before disassembling work.
Step
Procedure Points
1
Open the front panel
over the position where
it stops.
2
Slide the left rotary
shaft to the right and
release it.
When reassembling the front
panel, fit the right and left rotary
shafts one by one into the
grooves and fully push them into
position.
3
Slide the right rotary
shaft to the left and
release it.
4
Remove the front
panel.
To Next Page
