Daikin VRV Service Manual

List of Applicable Models of TYPE3 Si30-408
128 Service Checker Type3 Application Edition
1. List of Applicable Models of TYPE3
1.1 VRV Multi Systems (R410A/R407C/R22)
*1 Connect to a functional unit.
*2 VRV Plus (Cooling only, Heat pump) for high outdoor temperature use up to 50degC. Condenser Unit.
*3 On VRV II heat recovery series, outdoor unit data is split off into common and individual sections.
Consequently, two units of icons are displayed even for a single outdoor unit.
If two or more outdoor units are included in the system, icons for s single outdoor unit + Another one unit will be
displayed.
*4 Be aware that, on models equipped with D3-NET for the transmission system between indoor and outdoor units,
data on indoor units changes at intervals of several minutes.
*5 “E: Resistant to salt damage”, “G: Resistant to serious salt damage”, or “Y: Export voltage”, which is the suffix on a
model name, is omitted.
*6 With D3-NET connected, be aware that this Service Checker cannot be used in combination with “Remote control
adapter” or “Individual use of schedule timer”.
Connection
D3 D3-NET connection
Soft. Ver.
Support software version
(A blank is Ver. 1.03 or before it.)
PCB PCB connection
VRV series-HFC Connection
Soft.
Ver.
Type Model D3 PCB
R410A
VER II “M” series Heat Pump RXYQ5-48M (Y1) 0 1.07
Heat Recovery REYQ5-48M (Y1) 0 1.08
R407C
VRV “K” series Heat Pump RSXYP5-10K(JY1) 0 0
Heat Recovery RSEYP8-10K(JY1) 0 1.04a
VRV plus series Cooling Only RSXP16-30K(Y1) 0 1.06
Heat Pump RSXYP16-30K(JY1) 0 1.05
Heat Recovery RSEYP16-30K(JY1) 0 1.06
VRV “L” series Heat Pump RSXYP5-10L(JY1, Y1, YL) 0 1.06
VRV series-R22 Connection
Soft.
Ver.
Type Model D3 PCB
VRV “G” series Cooling Only RSX8G, 10G(Y1, YAL) 0
Heat Pump RSXY5-10G(Y1, YAL) 0
Heat Recovery RSEY8G, 10G(Y1) 0
VRV “H” series Cooling Only RSX5-10H(Y1) 0
Heat Pump RSXY5-10H(Y1, YAL, TAL) 0
VRV “K” series Cooling Only RSX5-10K(Y1, TAL) 0 0
RSX5-10K(UY1) 0 0
Heat Pump RSXY5-10K(Y1, YAL, TAL) 0 0
RSXY5-10K(7W1) 0 0
Heat Recovery RSEY8-10K(Y1) 0
RSEY8-10KL(Y1) 0 1.04a
VRV plus series Cooling Only RX16-30K(Y1, YAL) (C unit) 0 0 *1
Heat Pump RXY16-30K(Y1, YAL) (L unit) 0 0 *1
RXY16-30KA(Y1, YAL) 0 1.05
Heat Recovery REY16-30K(Y1) (R unit) 0 0 *1
Condenser Unit RXE2-3KVAL *2 0 1.04b
VRV II “M” series Cooling Only RX5-48M(Y1) 0 1.07
Heat Pump RXY5-48M(TL, YL) 0 1.07
VRV system for Hi-outdoor temp. use RSNY8KTAL 0 0
