Daikin VRV Service Manual

Si30-408 List of VRV Unit Models
Introduction 3
2. List of VRV Unit Models
2.1 List of Outdoor Unit Models
Type R22 C to H series R22 K series
Standarad Comp. Type
VRV Standard C series VRV for High outdoor temp (with unloader comp.)
Model Type
Service manual Model Type Service manual
—
RSC10,15C
—
Cooling only
—
(ES20-2)
RSNY8KTAL Heat-pump Si-06
VRV Standard D series
Model Type
Service manual
RSCY10,15D
—
Heat-pump
—
Si-46A
—
VRV Standard G series
Model Type
Service manual
RSCY5,10 G
RSC5,10G
Heat-pump
Cooling only
Si-45F
Si-45F
VRV Standard F series
Model Type
Service manual
RSCY10,15F
RSC10,15F
Heat-pump
Cooling only
Si-46A
Si-46A
Small Capacity Inverter Type
VRV Inverter G series VRV Inverter K series
Model Type
Service manual Model Type Service manual
RSXY5-10G(J)
RSX8,10G(J)
RSEY8,10G(J)
Heat-pump
Cooling only
Heat recovery
Si-45F
Si-45F
Si-45F
RSXY5-10K
RSX5-10K
RSEY8,10K
Heat-pump
Cooling only
Heat recovery
Si-05C
Si-05C
—
VRV Inverter H series VRV Inverter KU series
Model Type
Service manual Model Type Service manual
RSXY5-10H(J)
RSX5-10H(J)
Heat-pump
Cooling only
Si-46C
Si-46C
RSX5-10KU Cooling only Si-91
VRV Inverter KA series
Model Type
Service manual
RSX5-10KA Cooling only Si-92
VRV Inverter K series (H/R with Scroll Comp.)
Model Type
Service manual
RSEY8-10KLY1
Heat recovery Si-95
High COP
Inverter Type
Large Capacity Inverter Type
VRV Plus series
Model
Function unit Inverter Cnstant Speed Type Service manual
RXY16-30K
RX16-30K
REY16-30K
BL2 or 3K
BC2 or 3K
BR2 or 3K
RXY8 or 10K
RX8 or 10K
RXY8 or 10K
RNY8 or 10K
RN8 or 10K
RNY8 or 10K
Heat-pump
Cooling only
Heat recovery
Si-05C
Si-05C
Si-11
VRV Plus series for High outdoor temp
Model
Function unit Inverter Cnstant Speed Condenser Type Service manual
RXY16-30K-K
RX16-30K-K
BL2 or 3K
BC2 or 3K
RXY8 or 10K
RX8 or 10K
RNY8 or 10K
RN8 or 10K
RXE2 or 3K
RXE2 or 3K
Heat-pump
Cooling only
Si-94
Si-94
VRV R22 Plus series
Model Main unit Sub unit Type
Service manual
RSXY16-30KA RXY8 or 10KA RXE8 or 10KA Heat-pump Si33-101
VRV II series
Model Module Type
Service manual
RXY5-48M
RX5-48M
RXY8-16M
RX8-16M
Heat-pump
Cooling only
Si38-304
Si38-304
