Danfoss EKE 347 User Manual

User Guide | Liquid level controller, EKE 347
© Danfoss | DCS (ADAP-KOOL®) | 2016-04
DKRCI.PD.RP0.A4.02 | 14
AKS 4100/
AKS 4100U
Danf
oss
M84H0084_1
MASTER
I/O
AKVA
(ICAD)
R120 CAN H CAN L GND
15 16 17 18
R120 CAN H CAN L GND
15 16 17 18
Jumper
15-16
Jumper
15-16
D02
D03
D01
NC 2 C 2 NO 2
NC 3 C 3 NO 3
NO 1 C 1 NC 1
When more controllers are
connected via CAN bus each end
of the bus must be terminated
with a jumper between 15 and 16.
I/O conguration
Remote display
Example 1
Termination
Termination
The daily operation can be set up directly on the
controller or via an external display device.
