Setup & service menu - COMMISSIONING (Continued)
Parameter Options
Default
values
Service Controller state -
Actual level -
Actual referrence -
Actual OD -
Actual valve position
Digital input status -
Actual level signal voltage
Actual level signal current -
Actual position signal voltage
Actual position signal current
Actual OD A
Actual OD B
Actual OD C
Manual Mode On, O O
Manual OD 0 - 100% 50.0%
Manual low alarm O-On O
Manual high alarm O-On O
Manual common alarm O-On On
Apply defaults None, Factory None
Setup wizard Setup wizard Re-run Setup wizard -
I/O check Main switch EKE act: O
AKS 4100 EKE act: -
ICAD EKE act: -
Nor. Close (NC) EKE act: -
Upper lvl (alarm) EKE act: -
Lower lvl (alarm) EKE act: -
Controller name Controller name Type in controller name -
Read & Write
Read only
Alarm and error codes:
When detecting an alarm from external sources or the ashing bell in the display,
the alarm description can be found as a text message in the Status menu under
Active alarms.
Both alarms and errors will be shown here.
If more alarms/errors occur simultaneously, they will be shown as subsequent text
lines.
Alarms:
Upper level
Lower level
Standby mode
Valve B CAN ID conict
Valve C CAN ID conict
IO module CAN ID conict
IO module communication
Communication to master lost
Min/max OD conict
Common alarm HW conict
Control method conict
Multiple valve setup conict
Valve C alarm
Valve B alarm
Oscillation in level signal
Valve position
Multiple valve capacity
Valve C communication
Valve B communication
Errors:
Internal error
Level signal out of range
Valve position signal out of range
Sensor supply overload
AKS 4100 error
Too much current AI3
Too much current AI4
DO4 overload
