Data
Supply voltage
24 V a.c. +/-20% 50/60 Hz or 24 V d.c. +/-20%
(the supply voltage is galvanically separated from the input and output signals.
Input/output are not individual galvanic isolated)
Power consumption
Controller
20 W coil for AKV or AKVA
15 VA / 10W
55 VA
Input signal
* Ri =
0(4)-20mA: 33 ohm
0(2)-10 V: 100 kohm
Level signal * 4-20 mA or 0-10 V
ICM valve feedback signal * From ICAD 0/4-20 mA
Contact function start/stop of regulation
Relay output
3 pcs. SPDT (Lower level alarm, Upper level alarm,
Common alarm / NC Solenoid)
Normally Open:
3 A GP*, 2.2 FLA / 13.2 LRA, 1/6 hp, PD 220 VA, 250 V a.c. 100 k
3 FLA / 18 LRA, 1/10 hp, PD 150 VA, 125 V a.c. 100 k
Normally Closed:
3 A GP*, 250 V a.c. 100 k
(*GP = General purpose).
Max 240 V a.c. or 24 V a.c./d.c. can be used, but same voltage type must be
used on DO3 and DO2
Current output
0-20 mA or 4-20 mA
Max. load: 500 ohm
Valve connection
ICM - via current output
AKV/A- via 24 a.c. Pulse-Width Modulating output
Data communication
MODBUS RTU: Communication to system controller,
MODBUS on RS485: galvanic isolation (500 V d.c.)
CAN: Communication to other EKE controllers
Supported Modbus
Commands
Supported commands with max of 50 ms re-
sponse time
03 (0x03) Read Holding Registers
04 (0x04) Read Input Registers
06 (0x06) Write Single Register
Supported commands without dened max re-
sponse time
08 (0x08) Diagnostics
16 (0x10) Write Multiple Registers (up to 20 registers)
43 (0x2b) Read Device Identication
Environments
–20 - 55°C, during operation
–30 - 80°C, during storage
90% Rh, not condensed
No shock inuence / vibrations
Enclosure IP 20 /IP 40 for the front mounted into a panel
Weight 193 g
Mounting DIN rail
Display Graphical LCD display
Terminals plugs 1.5 or 2.5 mm
2
multicore
Approvals
EU Low Voltage Directive and EMC demands re CE-marking complied with.
LVD-tested acc. to EN 60730-1 and EN 60730-2-9
EMC-tested acc. to EN61000-6-3 and EN 61000-6-2
UL le E31024
Ordering
Type Description Code No.
EKE 347 Liquid level controller 080G5000
MMIGRS2 Remote display, Panel, S 080G0294
-
Wire for display unit, L = 1.5 m, 1 pcs. 080G0075
-
Wire for display unit, L = 3 m, 1 pcs. 080G0076
-
EKE / EKC accessory for panel mounting 027F0309
