DKRCI.PD.RP0.A4.02 | 16
Label Parameter name Min
value
Max
value
Default Unit Deci-
mals
Modbus
PNU
Locked
by main
switch
EEPROM Enumeration
r12 Main switch 0 1 0 0 3001 NO YES 0 = O | 1 = On
R01 Liquid level setpoint 0 100 50 % 1 3002 NO YES
N07 Operation Mode 0 2 0 0 3003 YES YES 0 = Master | 1 = Slave | 2 = IO
a02 Lower level limit 0 100 15 % 0 3004 NO YES
a01 Upper level limit 0 100 85 % 0 3005 NO YES
a07 Level alarm mode 0 1 0 0 3006 NO YES 0 = Time | 1 = Hysteresis
a04 Lower delay 0 999 10 s 0 3007 NO YES
a03 Upper delay 0 999 50 s 0 3008 NO YES
a06 Lower level hysteresis 0 20 3 % 1 3009 NO YES
a05 Upper level hysteresis 0 20 5 % 1 3010 NO YES
a08 Function common alarm 0 3 0 0 3011 NO YES 0 = Not follow | 1 = Follow up | 2 = Fol-
low low | 3 = Follow all
a12 Oscillation detect band 0 100 100 % 0 3012 NO YES
a13 Oscillation detect timeout 2 30 20 min 0 3013 NO YES
a25 Force pump OFF in stopped mode 0 1 0 0 3117 NO YES 0 = O | 1 = On
a14 IO Lower level limit 0 100 5 % 0 3101 NO YES
a15 IO Upper level limit 0 100 95 % 0 3102 NO YES
a16 IO Lower level hysteresis 0 20 3 % 1 3103 NO YES
a17 IO Upper level hysteresis 0 20 3 % 1 3104 NO YES
a18 IO Lower delay 0 999 10 s 0 3105 NO YES
a19 IO Upper delay 0 999 50 s 0 3106 NO YES
a20 IO Level limit 0 100 50 % 0 3107 NO YES
a21 IO Level delay 0 999 10 s 0 3108 NO YES
a22 IO Level hysteresis 0 20 3 1 3109 NO YES
a23 IO Level action 0 1 0 0 3110 NO YES 0 = Falling | 1 = Rising
N03 Control Method 0 2 2 0 3014 NO YES 0 = On/o | 1 = P-ctrl | 2 = PI-ctrl
n35 Regulating principle 0 1 0 0 3015 NO YES 0 = Low | 1 = High
n04 P-band 5 200 30 % 1 3016 NO YES
n05 Integration time Tn 60 600 400 s 0 3017 NO YES
n34 Neutral zone 0 25 2 % 1 3018 NO YES
N06 Dierence 0,5 25 2 % 1 3019 NO YES
n13 Period time for AKV/AKVA 3 15 6 s 1 3020 NO YES
n33 Minimum OD 0 0 % 0 3021 NO YES
n32 Maximum OD 1 100 100 % 0 3022 NO YES
o11 Language 0 0 0 0 3023 YES YES 0 = $ActiveLanguageList
o17 Output indication 0 1 0 0 3024 NO YES 0 = Level | 1 = OD
K04 Login timeout 1 120 10 min 0 3025 NO YES
K06 Backlight timeout 0 120 2 min 0 3026 NO YES
o05 Password daily 0 999 100 0 3027 NO YES
K02 Password service 0 999 200 0 3028 NO YES
K03 Password commission 0 999 300 0 3029 NO YES
K05 Contrast 0 100 40 % 0 3030 NO YES
K01 Brightness 0 100 80 % 0 3031 NO YES
I09 System conguration 0 4 0 0 3032 YES YES 0 = ICAD+NC | 1 = ICAD | 2 = AKV/A+NC
| 3 = AKV/A | 4 = NC only
o31 Level signal setup 0 3 0 0 3033 YES YES 0 = AKS4100 | 1 = AKS41 | 2 = Current |
3 = Voltage
o32 Voltage at low liquid level 0 0 V 1 3034 NO YES
o33 Voltage at high liquid level 10 10 V 1 3035 NO YES
I06 Current at low liquid level 0 4 mA 1 3036 NO YES
I07 Current at high liquid level 20 20 mA 1 3037 NO YES
o34 Valve position setup 0 2 0 0 3038 YES YES 0 = Not used | 1 = Current | 2 = Voltage
I02 Voltage at closed valve position 0 0 V 1 3039 NO YES
I03 Voltage at open valve position 10 10 V 1 3040 NO YES
I04 Current at closed valve position 0 4 mA 1 3041 NO YES
I05 Current at open valve position 20 20 mA 1 3042 NO YES
I18 Common alarm setup 0 3 1 0 3043 YES YES 0 = DO4 | 1 = High Alarm | 2 = DO3 | 3
= Disp only
I08 Multiple valve setup 0 4 0 0 3044 YES YES 0 = Not used | 1 = 2 same cap | 2 = 2 dif
cap | 3 = 3 same cap | 4 = 3 dif cap
I13 Multiple valve pattern 0 1 0 0 3045 NO YES 0 = Parallel | 1 = Sequence
I10 Valve A capacity 0 100 50 % 0 3046 YES YES
