Danfoss ICAD 1200B User Manual

Label ID
Parameter
name
Description and selection
options
Min.
Max.
Factory set‐
ting
Modbus
address
Alterna‐
tive
Modbus
address
Size in
bytes
Pass‐
word
level to
Read -
Write
Read
only
(RO) /
Read
Write
(RW) /
Write
(W)
Persis‐
tent
Yes/No
Modbus
func‐
tion
ID237
Modbus
enable
Enable/disable Modbus to
manage if data can be read
and set via Modbus connec-
tion. 1: enable; 0: disable
0
1
1
3104
3395
1
1 - 2
RW
Yes
3 & 6, 16
ID155
Modbus
heartbeat
enable
Active when ID2 is modulat-
ing and ID3 is modbus
1: enable; 0: disable
0
1
0
3093
3378
2
1 - 2
RW
Yes
3 & 6, 16
ID156
Modbus
heartbeat
interval
When ID155 Modbus heart-
beat is enabled.
The interval with which the
PLC should send Modbus re-
quests to ICAD.
If the ICAD does not receive
any (read/write parameter)
Modbus request during this
interval, the A3 Alarm (signal
lost) will be set 5…120 sec-
onds (min step – 1)
5
120
30
3094
3379
2
1 - 2
RW
Yes
3 & 6, 16
Status/I/O Status
Label ID
Parameter
name
Description and selection
options
Min.
Max.
Factory set‐
ting
Modbus
address
Alterna‐
tive
Modbus
address
Size in
bytes
Pass‐
word
level to
Read -
Write
Read
only
(RO) /
Read
Write
(RW) /
Write
(W)
Persis‐
tent
Yes/No
Modbus
func‐
tion
ID37
DI
Readout the digital input
when the operation mode
(ID2) is set to ON/OFF or 3-
point control.
3: DI1 - on, DI2 - on;
2: DI1 - o, DI2 - on;
1: DI1- on, DI2 - o;
0: DI1- o, DI2 - o; Note
that for ON/OFF only DI1 is
active:
1: DI1 - on
0: DI1 - o
0
3
0
3044
3328
1
1
RO
No
3
ID38
DO (fully
close)
DO Fully closed status (ON
when OD < 3%)
1: Yes;
0: No
0
1
0
3045
3329
1
1
RO
No
3
ID39
DO (fully
open)
DO Fully opened status (ON
when OD > 97%)
1: Yes;
0: No
0
1
0
3046
3330
1
1
RO
No
3
ID40
DO (alarm
show)
DO common alarm status
(Active when there are ac-
tive alarms)
1: Active;
0: OFF
0
1
0
3047
3331
1
1
RO
No
3
© Danfoss | Climate Solutions | 2024.01 BC465027827472en-000102 | 27
ICM and ICMTS Motorized Valves with ICAD Actuators
