Danfoss ICAD 1200B User Manual

Non-displayed Parameters
Label ID
Parameter
name
Description and selection
options
Min.
Max.
Factory set‐
ting
Modbus
address
Alterna‐
tive
Modbus
address
Size in
bytes
Pass‐
word
level to
Read -
Write
Read
only
(RO) /
Read
Write
(RW) /
Write
(W)
Persis‐
tent
Yes/No
Modbus
func‐
tion
ID55
Screen saver
Manage the time elapsed
without user actions before
the built-in display of ICAD
goes to sleep mode (in sec-
onds). Pressing any button
ends the screen saver mode
30
1200
360
3090
3380
2
1 - 2
RW
Yes
3 & 6,
16
ID226
Status
Readout the current ICAD
status
6: Cong: ICAD continues to
operate as before. In cong
mode parameters can be
changed but are not applied
until setting main switch
back to auto or manual
5: Valve detection: ICAD is
currently detecting a valve
4: Safe state: ICAD has stop-
ped operation and applied
the emergency state setting
(ID20) 3: Boost: ICAD is cur-
rently boosting to achieve
the requested position
2: Calibration: ICAD is cur-
rently calibrating
1: Manual: User manually
sets the valve position to be
maintained
0: Auto: Input signal type
(ID3) controls valve position
0
6
0
3051
3322
1
1
RO
No
3
ID33
Current OD
Readout the opening degree
(OD).
OD by encoder when encod-
er operation (ID15) is on,
else OD by internal counter.
0…10000 points, where 100
= 1%
(I.e. 5219 = 052.19%; 10000
= 100.00%)
0
10000
0
3040
3323
2
1
RO
No
3
ID211
Requested
OD
Readout the requested
opening degree automati-
cally matching the settings
for input type and operation
mode. 0…10000 points,
where 100 = 1%
(I.e. 5219 = 052.19%; 10000
= 100.00%)
0
10000
0
3053
3324
2
1
RO
No
3
ID254
Current
access level
Readout the current access
level corresponding to user
login. This manages rights
for reading and writing pa-
rameters, and controls what
the user sees
3:Danfoss Admin;
2: Service;
1: Read only
1
3
1
3058
3340
1
1-2
RW
No
3
ID239
Battery
voltage
Readout the current voltage
of the UPS battery, when
this is attached and enabled.
0...300 points, where 10 = 1V
(I.e. 234 = 23.4V; 100 =
10.0V)
0
300
0
3059
3341
1
1
RO
No
3
ICM and ICMTS Motorized Valves with ICAD Actuators
© Danfoss | Climate Solutions | 2024.01 BC465027827472en-000102 | 36
