Danfoss ICAD 1200B User Manual

Status/Next Service
Label ID
Parameter
name
Description and selection
options
Min.
Max.
Factory set‐
ting
Modbus
address
Alterna‐
tive
Modbus
address
Size in
bytes
Pass‐
word
level to
Read -
Write
Read
only
(RO) /
Read
Write
(RW) /
Write
(W)
Persis‐
tent
Yes/No
Modbus
func‐
tion
ID233
Time overdue
Once the service interval has
passed, and Time to next
service (ID50) has reached 0,
the time overdue is calcula-
ted. Time is updated every
30 minutes and calculated
as full days (24 hours) based
on runtime. 0...32764 (in
days)
0
32764
0
3063
3350
2
1
RO
Yes
3
ID50
Time to next
service
Readout the days remaining
of the current service inter-
val (ID234). Time is updated
every 30 minutes and calcu-
lated as full days (24 hours)
based on runtime. 0…999
(in days)
0
999
365
3064
3351
2
1
RO
Yes
3
ID48
Run time
Readout the run time in full
hours for the ICAD from
when it was rst powered on
or factory reset. Saved every
30min 0…4294967293 (in
minutes)
0
4294967293
0
3060 ...
3061
3347 ...
3348
4
1
RO
Yes
3
Status/Supply
Label ID
Parameter
name
Description and selection
options
Min.
Max.
Factory set‐
ting
Modbus
address
Alterna‐
tive
Modbus
address
Size in
bytes
Pass‐
word
level to
Read -
Write
Read
only
(RO) /
Read
Write
(RW) /
Write
(W)
Persis‐
tent
Yes/No
Modbus
func‐
tion
ID228
Power supply
voltage (V)
Readout the current power
supply voltage to ICAD in
Volt. 0...300 points, where 10
= 1V (I.e. 234 = 23.4V; 100 =
10.0V)
0
300
0
3054
3336
2
1
RO
No
3
ID227
UPS health
Readout the state of the
UPS. Only active when UPS
supply (ID21) is set to yes
and the UPS setting (ID22) is
not set to o.
1: OK;
0: Poor
0
1
0
3052
3335
1
1
RO
No
3
ICM and ICMTS Motorized Valves with ICAD Actuators
© Danfoss | Climate Solutions | 2024.01 BC465027827472en-000102 | 28
