Danfoss PVG 16 Technical Information

PVG 128/16 Dimensions
The table of PVB 128 and PVB 16 combination valve stack dimensions overview table with accompanying
drawing.
L1
L3
95 [3.74]
132 [5.20]
L2
PVB 128/PVB 16 valve stack dimensions, mm [in]
Number
of PVB
128
(down)
Number of PVB 16
1 2 3 4 5 6 7 8 9 10 11
1 L1 173
[6.81]
213
[8.39]
253
[9.96]
293
[11.54]
333
[13.11]
373
[14.69]
413
[16.26]
453
[17.83]
493
[19.41]
533
[20.98]
573
[22.56]
L2 297,5
[11.71]
346,5
[13.64]
382,5
[15.06]
418,5
[16.48]
467,5
[18.41]
503,5
[19.82]
540,5
[21.28]
588,5
[23.17]
625,5
[24.63]
661,5
[26.04]
685,5
[26.99]
L3 98,5 [3.88]
2 L1 239
[9.41]
279
[10.98]
319
[12.56]
359
[14.13]
399
[15.71]
439
[17.28]
479
[18.86]
519
[20.43]
559
[22.01]
599
[23.58]
—
L2 370,5
[14.59]
406,5
[16.00]
455,5
[17.93]
491,5
[19.35]
528,5
[20.81]
576,5
[22.70]
588,5
[23.17]
649,5
[25.57]
697,5
[27.46]
734,5
[28.92]
—
L3 164,5 [6.48]
3 L1 305
[12.01]
345
[13.58]
385
[15.16]
425
[16.73]
465
[18.31]
505
[19.88]
545
[21.46]
585
[23.03]
— — —
L2 431,5
[16.99]
479,5
[18.88]
515,5
[20.30]
552,5
[21.75]
600,5
[23.64]
637,5
[25.10]
673,5
[26.52]
722,5
[28.44]
— — —
L3 230,5 [9.07]
4 L1 371
[14.61]
411
[16.18]
451
[17.76]
491
[19.33]
531
[20.91]
571
[22.48]
611
[24.06]
— — — —
L2 503,5
[19.82]
540,5
[21.28]
588,5
[23.17]
625,5
[24.63]
661,5
[26.04]
709,5
[27.93]
746,5
[29.39]
— — — —
L3 296,5 [11.67]
5 L1 437
[17.02]
477
[18.78]
517
[20.35]
557
[21.93]
597
[23.50]
— — — — — —
L2 564,5
[22.22]
612,5
[24.11]
649,5
[25.57]
685,5
[26.99]
734,5
[28.92]
— — — — — —
L3 362,5 [14.27]
Technical Information
PVG 16 Proportional Valve Group
PVG 16 Combinations Valve Stack Dimensions
104 |
©
Danfoss | December 2018 BC00000211en-000901
