Danfoss PVG 16 Technical Information

PVB 32/16 combination valve stack dimensions, mm [in] (continued)
Number
of PVB 32
(down)
Number of PVB 16 modules
1 2 3 4 5 6 7 8 9 10 11
9 L1 506
[19.92]
546
[21.50]
586
[23.07]
- - - - - - - -
L2 576
[22.68]
622
[24.49]
646
[25.43]
- - - - - - - -
10 L1 554
[21.81]
594
[23.39]
- - - - - - - - -
L2 622
[24.49]
670
[26.38]
- - - - - - - - -
11 L1 602
[23.70]
- - - - - - - - - -
L2 670
[26.38]
- - - - - - - - - -
Weight for a PVG 32/16 valve stack
The combined weight of a PVG 32/16 valve stack can be defined like this:
(Numbers of PVB 32 x 4,42) + (numbers of PVB 16 x 3,67) + 3,6 = Weight in kg
(Numbers of PVB 32 x 9.75) + (numbers of PVB 16 x 8.09) + 7.95 = Weight in lb
Technical Information
PVG 16 Proportional Valve Group
PVG 16 Combinations Valve Stack Dimensions
©
Danfoss | December 2018 BC00000211en-000901 | 99
