■ Factory settings
PNU
#
Parameter
description
Factory setting Range Changes
during
operation
4-setup Con-
version
index
Data
type
001 Language English Yes No 0 5
002 Active Setup Setup 1 Yes No 0 5
003 Copying of Setup No copying No No 0 5
004 LCP copy No copying No No 0 5
005 Max value of user-defined readout 100.00 0 - 999.999,99 Yes Yes -2 4
006 Unit for user-defined readout No unit Yes Yes 0 5
007 Big display readout Frequency, % of max. Yes Yes 0 5
008 Small display readout 1.1 Reference, Unit Yes Yes 0 5
009 Small display readout 1.2 Motor current, A Yes Yes 0 5
010 Small display readout 1.3 Power, HP Yes Yes 0 5
011 Unit of local reference Hz Yes Yes 0 5
012 Hand start on LCP Enable Yes Yes 0 5
013 OFF/STOP on LCP Enable Yes Yes 0 5
014 Auto start on LCP Enable Yes Yes 0 5
015 Reset on LCP Enable Yes Yes 0 5
016 Lock for data change Not locked Yes Yes 0 5
017 Operating state at power-up,
local control
Auto restart Yes Yes 0 5
100 Configuration Open loop No Yes 0 5
101 Torque characteristics Automatic Energy
Optimisation
No Yes 0 5
102 Motor power P
M,N
Depends on the unit 1.1-400 kW
(1.5-600 HP
No Yes 1 6
103 Motor voltage, U
M,N
Depends on the unit 208/480/575 V No Yes 0 6
104 Motor frequence, f
M,N
60 Hz/ 50 Hz 24-120 Hz No Yes 0 6
105 Motor current, I
M,N
Depends on the unit 0.01 - I
VLT,MAX
No Yes -2 7
106 Rated motor speed, n
M,N
Depends on
par. 102 Motor power
100-60000 rpm No Yes 0 6
107 Automatic motor adaptation,AMA Optimisation disable No No 0 5
108 VT start voltage Depends on par. 103 0.0 - par. 103 Yes Yes -1 6
109 Resonance dampening 100 % 0 - 500 % Yes Yes 0 6
110 High brake-away torque 0.0 sec. 0.0 - 0.5 sec. Yes Yes -1 5
111 Start delay 0.0 sec. 0.0 - 120.0 sec. Yes Yes -1 6
112 Motor preheater Disable Yes Yes 0 5
113 Motor preheater DC current 50 % 0 - 100 % Yes Yes 0 6
114 DC braking current 50 % 0 - 100 % Yes Yes 0 6
115 DC braking time 10 sec. 0.0 - 60.0 sec. Yes Yes -1 6
116 DC brake cut-in frequency OFF 0.0-par. 202 Yes Yes -1 6
118 Motor power factor 0.75 0.50-0.99 No Yes 0 6
117 Motor thermal protection ETR trip 1 Yes Yes 0 5
119 Load compensation at low speed 100 % 0 - 300 % Yes Yes 0 6
120 Load compensation at high speed 100 % 0 - 300 % Yes Yes 0 6
121 Slip compensation 100 % -500 - 500 % Yes Yes 0 3
122 Slip compensation time constant 0.50 sec. 0.05 - 5.00 sec. Yes Yes - 2 6
123 Stator resistance Depends on the choice
of motor
No Yes - 4 7
124 Stator reactance Depends on the choice
of motor
No Yes - 2 7
) Global factory setting different from North American factory setting.
MG.83.A2.02 - VLT is a registered Danfoss trademark
196
