Table 150: Power Losses for dU/dt Filter Option, 525–690 V [W]
Model
525–550 V [W]
551–690 V
–
NO
HO
NO
HO
N110
453
308
414
281
N132
204
146
187
134
N160
314
204
287
187
N200
498
314
456
287
N250
302
211
277
193
N315
427
302
390
277
N355
575
427
527
390
N400
800
565
733
523
N500
989
666
905
608
N560
585
450
535
412
N630
654
585
654
535
N710
959
715
878
654
N800
1430
1054
1308
964
11.6.8 Sine-wave Filter Losses
Table 151: Power Losses for Sine-wave Filter Option, 380–500 V
Model
380–440 V [W]
441–500 V [W]
–
NO
HO
NO
HO
N110
1050
732
843
598
N132
770
512
656
411
N160
1130
770
1039
656
N200
1823
1159
1522
1065
N250
1312
888
1117
742
N315
1969
1312
1630
1117
N355
2529
2103
2033
1703
N40
3242
2529
2685
2033
N450
3738
2821
3112
2685
N500
2205
1822
1732
1517
N560
2790
2205
2255
1732
AQ262141314214en-000301 / 130R0880 | 193Danfoss A/S © 2021.11
Appendix
VLT® HVAC Drive FC 102
Operating Guide
