Danfoss VLT FC 100 Operating Instructions

Mains Supply 6x525-690 V AC, 12-Pulse
FC 302 P900 P1M0 P1M2 P1M4
High/ Normal Load* HO NO HO NO HO NO HO NO
Typical Shaft output at 550 V [kW] 750 850 850 1000 1000 1100 1100 1250
Typical Shaft output at 575 V [HP] 1050 1150 1150 1350 1350 1550 1550 1700
Typical Shaft output at 690 V [kW] 900 1000 1000 1200 1200 1400 1400 1600
Enclosure IP21, IP54 without/ with
options cabinet
F12/F13 F12/F13 F12/F13 F14
Output current
Continuous
(at 550 V) [A]
988 1108 1108 1317 1317 1479 1479 1652
Intermittent (60 s overload)
(at 550 V) [A]
1482 1219 1662 1449 1976 1627 2218.5 1817.2
Continuous
(at 575/690 V) [A]
945 1060 1060 1260 1260 1415 1415 1580
Intermittent (60 s overload)
(at 575/690 V) [A]
1418 1166 1590 1386 1890 1557 2122 1738
Continuous KVA
(at 550 V) [KVA]
941 1056 1056 1255 1255 1409 1409 1574
Continuous KVA
(at 575 V) [KVA]
941 1056 1056 1255 1255 1409 1409 1574
Continuous KVA
(at 690 V) [KVA]
1129 1267 1267 1506 1506 1691 1348 1505
Max. input current
Continuous
(at 550 V ) [A]
962 1079 1079 1282 1282 1440 1440 1608
Continuous
(at 575 V) [A]
920 1032 1032 1227 1227 1378 1378 1538
Continuous
(at 690 V) [A]
920 1032 1032 1227 1227 1378 1378 1538
Max. cable size, motor [mm
2
(AWG
2)
)]
12x150
(12x300 mcm)
Max. cable size,mains F12 [mm
2
(AWG
2)
)]
8x240
(8x500 mcm)
Max. cable size,mains F13 [mm
2
(AWG
2)
)]
8x400
(8x900 mcm)
Max. cable size, brake [mm
2
(AWG
2)
)
6x185
(6x350 mcm)
Max. external mains fuses [A]
1
1600 2000 2500
Estimated power loss
at 600 V [W]
4)
13755 15592 15107 18281 18181 20825 18843 21464
Estimated power loss
at 690 V [W]
4)
14457 16375 15899 19207 19105 21857 19191 21831
F3/F4 Max added losses CB or
Disconnect & Contactor
556 665 634 863 861 1044 1016 1267
Max panel options losses 400
Weight,
enclosure IP21, IP54 [kg]
1246/ 1541 1246/ 1541 1280/1575 3077/3372
Weight, Rectifier Module [kg] 136
Weight, Inverter Module [kg] 102 136
Efficiency
4)
0.98
Output frequency 0-500 Hz
Heatsink overtemp. trip 85° C
Power card ambient trip 75° C
* High overload = 160% torque during 60 s, Normal overload = 110% torque during 60 s
1) For type of fuse see section Fuses.
2) American Wire Gauge.
3) Measured using 5 m screened motor cables at rated load and rated frequency.
4) The typical power loss is at nominal load conditions and expected to be within ±15% (tolerence relates to
variety in voltage and cable conditions).
Values are based on a typical motor efficiency. Motors with lower efficiency will also add to the power loss in the
frequency converter and opposite.
If the switching frequency is increased compared to the default setting, the power losses may rise significantly.
LCP and typical control card power consumptions are included. Further options and customer load may add up to
30 W to the losses. (Though typical only 4 W extra for a fully loaded control card, or options for slot A or slot B,
each).
Although measurements are made with state of the art equipment, some measurement inaccuracy must be
allowed for (±5%).
General Specifications
VLT
®
Automation Drive FC 300 12-Pulse
Operating Instructions High Power
MG34Q202 - VLT
®
is a registered Danfoss trademark 103
5 5
