Par. No. # Parameter description Default value 4-set-up Change during
operation
Conver-
sion index
Type
15-0* Operating Data 15-00 Operating Hours 0 h All set-ups FALSE 74 Uint32 15-01 Running Hours 0 h All set-ups FALSE 74 Uint32
15-02 kWh Counter 0 kWh All set-ups FALSE 75 Uint32
15-03 Power Up's 0 N/A All set-ups FALSE 0 Uint32
15-04 Over Temp's 0 N/A All set-ups FALSE 0 Uint16
15-05 Over Volt's 0 N/A All set-ups FALSE 0 Uint16
15-06 Reset kWh Counter [0] Do not reset All set-ups TRUE - Uint8
15-07 Reset Running Hours Counter [0] Do not reset All set-ups TRUE - Uint8
15-08
Number of Starts 0 N/A All set-ups FALSE 0 Uint32
15-1* Data Log Settings 15-10 Logging Source 0 2 set-ups TRUE - Uint16 15-11 Logging Interval ExpressionLimit 2 set-ups TRUE -3 TimD
15-12 Trigger Event [0] False 1 set-up TRUE - Uint8
15-13 Logging Mode [0] Log always 2 set-ups TRUE - Uint8
15-14
Samples Before Trigger 50 N/A 2 set-ups TRUE 0 Uint8
15-2* Historic Log 15-20 Historic Log: Event 0 N/A All set-ups FALSE 0 Uint8 15-21 Historic Log: Value 0 N/A All set-ups FALSE 0 Uint32
15-22 Historic Log: Time 0 ms All set-ups FALSE -3 Uint32
15-23 Historic Log: Date and Time ExpressionLimit All set-ups FALSE 0 TimeOfDay 15-3* Alarm Log 15-30 Alarm Log: Error Code 0 N/A All set-ups FALSE 0 Uint8 15-31 Alarm Log: Value 0 N/A All set-ups FALSE 0 Int16 15-32 Alarm Log: Time 0 s All set-ups FALSE 0 Uint32
15-33
Alarm Log: Date and Time ExpressionLimit All set-ups FALSE 0 TimeOfDay
15-4* Drive Identification 15-40 FC Type 0 N/A All set-ups FALSE 0 VisStr[6] 15-41 Power Section 0 N/A All set-ups FALSE 0 VisStr[20]
15-42 Voltage 0 N/A All set-ups FALSE 0 VisStr[20]
15-43 Software Version 0 N/A All set-ups FALSE 0 VisStr[5]
15-44 Ordered Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
15-45 Actual Typecode String 0 N/A All set-ups FALSE 0 VisStr[40]
15-46 Frequency Converter Ordering No 0 N/A All set-ups FALSE 0 VisStr[8]
15-47 Power Card Ordering No 0 N/A All set-ups FALSE 0 VisStr[8]
15-48 LCP Id No 0 N/A All set-ups FALSE 0 VisStr[20]
15-49 SW ID Control Card 0 N/A All set-ups FALSE 0 VisStr[20]
15-50 SW ID Power Card 0 N/A All set-ups FALSE 0 VisStr[20]
15-51 Frequency Converter Serial Number 0 N/A All set-ups FALSE 0 VisStr[10]
15-53 Power Card Serial Number 0 N/A All set-ups FALSE 0 VisStr[19]
6.2.14. 15-** FC Information
VLT
®
HVAC Drive Operating Instructions 6. How to programme the frequency converter
MG.11.A4.02 - 09.10.06. VLT
®
is a registered Danfoss trademark 105
6
