Par. No. # Parameter description Default value 4-set-up Change during
operation
Conver-
sion index
Type
23-0* Timed Actions 23-00 ON Time ExpressionLimit 2 set-ups TRUE 0
TimeOfDay-
WoDate
23-01 ON Action [0] Disabled 2 set-ups TRUE - Uint8
23-02 OFF Time ExpressionLimit 2 set-ups TRUE 0
TimeOfDay-
WoDate
23-03 OFF Action [0] Disabled 2 set-ups TRUE - Uint8
23-04 Occurrence [0] All days 2 set-ups TRUE - Uint8
23-1* Maintenance 23-10 Maintenance Item [1] Motor bearings 1 set-up TRUE - Uint8 23-11 Maintenance Action [1] Lubricate 1 set-up TRUE - Uint8
23-12 Maintenance Time Base [0] Disabled 1 set-up TRUE - Uint8
23-13 Maintenance Time Interval 1 h 1 set-up TRUE 74 Uint32
23-14 Maintenance Date and Time ExpressionLimit 1 set-up TRUE 0 TimeOfDay
23-1* Maintenance Reset 23-15 Reset Maintenance Word [0] Do not reset All set-ups TRUE - Uint8 23-5* Energy Log 23-50 Energy Log Resolution [5] Last 24 Hours 2 set-ups TRUE - Uint8 23-51 Period Start ExpressionLimit 2 set-ups TRUE 0 TimeOfDay
23-53 Energy Log 0 N/A All set-ups TRUE 0 Uint32
23-54 Reset Energy Log [0] Do not reset All set-ups TRUE - Uint8
23-6* Trending
23-60 Trend Variable [0] Power [kW] 2 set-ups TRUE - Uint8
23-61 Continuous Bin Data 0 N/A All set-ups TRUE 0 Uint32
23-62 Timed Bin Data 0 N/A All set-ups TRUE 0 Uint32
23-63 Timed Period Start ExpressionLimit 2 set-ups TRUE 0 TimeOfDay
23-64 Timed Period Stop ExpressionLimit 2 set-ups TRUE 0 TimeOfDay
23-65 Minimum Bin Value ExpressionLimit 2 set-ups TRUE 0 Uint8
23-66 Reset Continuous Bin Data [0] Do not reset All set-ups TRUE - Uint8
23-67 Reset Timed Bin Data [0] Do not reset All set-ups TRUE - Uint8
23-8* Payback Counter 23-80 Power Reference Factor 100 % 2 set-ups TRUE 0 Uint8 23-81 Energy Cost 1.00 N/A 2 set-ups TRUE -2 Uint32
23-82 Investment 0 N/A 2 set-ups TRUE 0 Uint32
23-83 Energy Savings 0 kWh All set-ups TRUE 75 Int32
23-84 Cost Savings 0 N/A All set-ups TRUE 0 Int32
6.2.20. 23-** Timed Actions
VLT
®
HVAC Drive Operating Instructions 6. How to programme the frequency converter
MG.11.A4.02 - 09.10.06. VLT
®
is a registered Danfoss trademark 115
6
