Danfoss VLT HVAC User Manual

Surroundings:
Enclosure  enclosure type A IP 20, IP 55
Enclosure  enclosure type A, B IP 21, IP 55
Enclosure kit available  enclosure type A IP21/TYPE 1/IP 4X top
Vibration test 1.0 g
Max. relative humidity 5% - 95%(IEC 721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 721-3-3), uncoated class 3C2
Aggressive environment (IEC 721-3-3), coated class 3C3
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature Max. 50 °C
Derating for high ambient temperature, see section on special conditions
Minimum ambient temperature during full-scale operation 0 °C
Minimum ambient temperature at reduced performance - 10 °C
Temperature during storage/transport -25 - +65/70 °C
Maximum altitude above sea level without derating 1000 m
Maximum altitude above sea level with derating 3000 m
Derating for high altitude, see section on special conditions
EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EMC standards, Immunity
EN 61800-3, EN 61000-6-1/2,
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN
61000-4-6
See section on special conditions
Control card performance:
Scan interval : 5 ms
Control card, USB serial communication:
USB standard 1.1 (Full speed)
USB plug USB type B “device” plug
Connection to PC is carried out via a standard host/device USB cable.
The USB connection is galvanically isolated from the supply voltage (PELV) and other
high-voltage terminals.
The USB connection is
not galvanically isolated from protection earth. Use only iso-
lated laptop/PC as connection to the USB connector on VLT HVAC Drive or an isolated
USB cable/converter.
8.2. Special Conditions
8.2.1. Purpose of derating
Derating must be taken into account when using the frequency converter at low air pressure
(heights), at low speeds, with long motor cables, cables with a large cross section or at high
ambient temperature. The required action is described in this section.
8.2.2. Derating for Ambient Temperature
The average temperature (T
AMB, AVG
) measured over 24 hours must be at least 5 °C lower than
the maximum allowed ambient temperature (T
AMB,MAX
).
8. Specifications VLT
®
HVAC Drive Operating Instructions
138 MG.11.A4.02 - 09.10.06. VLT
®
is a registered Danfoss trademark
