Parameter Number Parameter Description Default Value 2 Setup Change During Operation Conversion Index Type
1 - 00 Configuration Mode [0] Speed open loop All set-ups TRUE - Uint8
1 - 01 Motor Control Principle
[1] VVC+ All set-ups FALSE
- Uint8
1 - 03 Torque Characteristics [0] Constant torque All set-ups TRUE - Uint8
1 - 05 Hand Mode Configuration
[2] As mode par 1-00 All set-ups TRUE
- Uint8
1 - 20 Motor Power All set-ups FALSE - Uint8
1 - 22 Motor Voltage
All set-ups FALSE
0 Uint16
1 - 23 Motor Frequency All set-ups FALSE 0 Uint16
1 - 24 Motor Current
All set-ups FALSE
-2 Uint16
1 - 25 Motor Nominal Speed All set-ups FALSE 0 Uint16
1 - 29 Automatic Motor Tuning (AMT)
[0] Off 1 set-up FALSE
- Uint8
1 - 30 Stator Resistance (Rs) All set-ups FALSE -2 Uint16
1 - 33 Stator Leakage Reactance (X1)
All set-ups FALSE
-2 Uint32
1 - 35 Main Reactance (Xh) All set-ups FALSE -2 Uint32
1 - 50 Motor Magnetisation at Zero Speed
100% All set-ups TRUE
0 Uint16
1 - 52 Min Speed Normal Magnetising [Hz] 0 Hz All set-ups TRUE -1 Uint16
1 - 55 U/f Characteristic - U
All set-ups TRUE
0 Uint16
1 - 56 U/f Characteristic - F All set-ups TRUE 0 Uint16
1 - 60 Low Speed Load Compensation
100% All set-ups TRUE
0 Uint16
1 - 61 High Speed Load Compensation 100% All set-ups TRUE 0 Uint16
1 - 62 Slip Compensation
100% All set-ups TRUE
0 Int16
1 - 63 Slip Compensation Time Constant 0.1 s All set-ups TRUE -2 Uint16
1 - 71 Start Delay
0 s All set-ups TRUE
-1 Uint8
1 - 72 Start Function [2] Coast/delay time All set-ups TRUE - Uint8
1 - 73 Flying Start
[0] Disabled All set-ups FALSE
- Uint8
1 - 80 Function at Stop [0] Coast All set-ups TRUE - Uint8
1 - 82 Min Speed for Function at Stop [Hz]
0 Hz All set-ups TRUE
-1 Uint16
1 - 90 Motor Thermal Protection [0] No protection All set-ups TRUE - Uint8
1 - 93 Thermistor Resource
[0] None All set-ups FALSE
- Uint8
5.2.6. 1-** Load/Motor
VLT
p
Micro Drive FC 51 5. Parameter Lists
MG.02.C4.02 - VLT
p
is a registered Danfoss trademark
69
5
