SD260L/SD360/SD460 Installation and Administrator’s Guide A-5
Bolt-Down Option
The laminator includes bolt-down openings that you can use to secure the system to a mounting
surface.
You need the following supplies:
 The bolt-down kit (part no. 509169-001) contains two M6 well nuts.
 Two M6 (6 mm) screws, purchased separately.
The length of the screws you need depends on the thickness of the mounting surface. The
screw length is the surface thickness + 0.75 inch (20 mm).
 Two M6 washers, purchased separately.
 1/4-inch (7 mm) drill bit.
1. Drill two holes in the mounting surface following the dimensions and requirements shown in
the following figure:
This procedure is optional.
