54 Printer Manager
FrontPanel
Use the FrontPanel settings to customize the printer front panel.
Change the front panel settings as needed, and then click Set Current to apply the changes.
BacklightBrightness—Set the LCD front panel backlight brightness at the desired level, from
0 percent (no backlight) to 100 percent (bright).
KeySenseLevel—Set the front panel key sensitivity to a comfortable level. Select from 0 (low
sensitivity, almost a press) to 10 (high sensitivity, barely a touch).
LcdConfigMenu—Enable or disable access to the Configuration menu on the LCD panel menu
system. (The Status and Maintenance menus cannot be disabled.)
LedCardsPickedToCleaning—Set the number of cards to pick between required cleaning. The
card light blinks amber when the printer reaches this value. If this value is set to 0, cards
between cleaning are not tracked. We recommend that you clean the printer after every 500
cards to maintain print quality.
LedPrintheadCyclesToCleaning—Set the number of printhead cycles between required
cleaning. The card light blinks amber when the printer reaches this value. If this value is set
to 0, cycles between cleaning are not tracked.
LedRibbonLow—Set the percentage of ribbon remaining before being notified that the
ribbon is low and should be changed. The ribbon light blinks amber when the ribbon reaches
this value.
SpeakerEnabled—Enable or disable the external printer speaker. The speaker provides a
sound in addition to the front panel lights and LCD text.
Description
Default
Value
Current Value
(unit)
Allowed
Range
1) BacklightBrightness 100 100 [0 – 100]
2) KeySenseLevel 5 5 [0 – 10]
3) LcdConfigMenu Enabled Enabled
4) LedCardsPickedToCleaning 500 500 [0 – 1000000]
5) LedPrintheadCyclesToCleaning 2500 2500 [0 – 1000000]
6) LedRibbonLow 10 10 [0 – 1000000]
7) SpeakerEnabled Enabled Enabled
