SD260L/SD360/SD460 Installation and Administrator’s Guide 11
Install the 200-Card Input Hopper
The standard input hopper can hold about 100 0.030 in. (0.762 mm) cards. The printers can be
upgraded to use a 200-card input hopper.
The 200-card input hopper kit includes the larger hopper with an attached cover. The standard
hopper can be removed, and the 200-card hopper can be installed, without using tools. You also
can refer to the instructions shipped with the 200-card input hopper kit.
1. Open the input hopper.
2. Press the release tab located on the
back wall of the hopper while lifting
the hopper up and off the printer.
3. Install the 200-card input hopper by
aligning the tabs with the slots on
the printer.
4. Push the hopper down until it clicks
into place.
5. Load up to 200 cards in the hopper
and close the hopper cover. The
printer is ready to print cards.
