90 Error Recovery and Messages

Mending a Broken Ink Ribbon or Retransfer Film

Iftheinkribbonorretransferfilmbreaks,InkSearchorMediaSearchisdisplayedontheLCD

panel.Brok eninkribbonisshowninthefollowingexample;repairingbrokenretransferfilmuses

thesamesteps.

1. Powerofftheprinter.

2. Opentheprinterdoor.

3. Pressthereleasebuttonfortheappropriate

cartridgeandremovethecartridgefromthe

printer.

4. Trimtheendsofthebrokenportionsevenly.

Donotremovetheusedinkribbonorfilmfromthetake‐upspool.

(Removingandthenreinstallingtheribbononthetake‐upspoolmay

causeprintqualityissuesforthenextfewcards.)

5. Aligntheendsofthebrokenmediaevenlyandapplytapetosecure

them.

6. Turnthetake‐upspoolcounterclockwiseuntilthemendedportionis

woundontothespooltwoorthreeturns.

7. Makesurethattheyellowpanelalignswiththearrowonthe

cartridge.

8. Reinstallthecartridgeinto

theprinteruntilitclicksintoposition.

9. Closetheprinterdoor.

10. Initializethesuppliesasdescribedin“InitializingtheInkRi bbonand

RetransferFilm”onpage 22.
