SR200 & SR300 Card Printers and LM200 & LM300 Laminators User’s Guide 23

Printing Cards Using ID Software

1. FollowtheinstructionsforyourIDsoftwaretocapture,format,andsavethedataforthe

card.

2. Inthesoftware,sendcardstotheprinter.

(Typically,youusethePrintbutton.)

Theprinterdriverreceivesdataforeachcard,

preparesthecardforprinting,andsendseach

cardtotheprinter.

Eachprintedcardexitstheprinterandis

depositedintothecardstackerorgoesdirectly

intothelaminator.

Printing Cards From a PC Application

1. Usethepagesetupfeatureinthesoftwareapplicationtosetthefollowing:

 SetpaperorpagesizetoCR80cardor2.125inchx3.375inch.

 Settheorientationforthecarddesign—eitherportraitorlandscape.

 Setmarginstozeroforedge‐to‐edgeprinting.

2. Formatandsavethecardinformation.

3. SelecttheSR‐CPU1printerfromthePrintdialogbox.

SR‐CPU1isthedefaultnameoftheprinterwhenconnected

withaUSBcable.Yourprintermayhaveadifferentname.

4. ClickPrinter

PropertiestoopenthePrinting

Propertiesdialogbox.UsetheSetup,Print,and

Encodetabstosetprinterproperties:

 SetupTab:Setthecardorientation,numberof

copies,andwhethertoturnthecardoverafter

 PrintTab:Setprintingononesideorbothsides,

androtation.ThePrinttabcontainssettingsfor

usingthecolor(YMC)andblack(K)panelsofthe

printribbon.Thistabalsocontainscontrolsfor

coloradjustment,settingupalook‐uptable,andspecifyingtheprintareaforribbon



panels,includingpeel‐offareas.

 EncodeTab:Vieworchangesettingsforusingsmartcard(IC)andmagneticstripe

encoding.Youcanalsospecifywhethertorotatethecardafteranencodingstep.
