DataCard SD360 Installation And Administrator's Guide

66 Printer Manager
Using custom magnetic stripe data formats is a two-step process. First, define the custom tracks
using MagStripeCustomTrack1, MagStripeCustomTrack2, and MagStripeCustomTrack3. Second,
apply the custom track using the settings on the MagStripeGeneral menu.
1. To use the defined custom track:
a. Open the MagStripeGeneral menu.
b. Select Custom for DataFormat1, DataFormat2, or DataFormat3 to use the custom track.
 MagStripeCustomTrack1 corresponds to DataFormat1
 MagStripeCustomTrack2 corresponds to DataFormat2
 MagStripeCustomTrack3 corresponds to DataFormat3
2. Click Set Current to apply the changes.
Laminator
The Laminator settings let you specify values when using a laminating system.
Description Default Value
Current Value
(unit) Allowed Range
1) DebowDelay 1000 1000 [0 – 1500]
2) ExceptionCardDebow
Direction
Down Down
3) ExceptionCardDebow
DistanceDown
15 15 [0 – 150]
4) ExceptionCardDebow
DistanceUp
105 105 [0 – 150]
5) ExceptionCardDebow
DwellMs
1000 1000 [0 – 5000]
6) ExceptionCardImpress
Depth
0 0 [-250 – 250]
7) ExceptionCardImpress
DwellTime
2000 2000 [0 – 10000]
8) ExceptionCardImpress
PositionOffset1
2000 2000 [0 – 4000]
9) ExceptionCardImpress
PositionOffset2
2000 2000 [0 – 4000]

DataCard SD360 Specifications

General

Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC
Card feeder	Yes
Print technology	Dye-sublimation
Maximum resolution	300 x 300 DPI
Print speed (color)	200 card/h
Print speed (monochrome)	830 card/h
Duplex print speed (color)	155 card/h
Display	LCD
Lamination	No
Certification	cULus, FCC, I.C, CE, Ctick, VCCI, RoHS, WEEE, ENERGY STAR, CCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Cable lock slot type	Kensington
Total input capacity	100 sheets
Compatible operating systems	Windows Server 2003/Server 2008
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Interface	USB & Ethernet

Weight and Dimensions

Weight	5400 g
Dimensions (WxDxH)	175 x 539 x 224 mm
