Datalogic PowerScan D8300 User Manual

Enter Configuration
Exit and Save Configuration
Ì$+;Î
16-KEY DK MODEL PARAMETERS
Ì$-?Î
158
QTY/CODE SEPARATOR
This feature allows the insertion of a separator between QTY/CODE pairs.

Disable – no separator
define QTY/CODE separator
 Read the above code.
 Select the length of the separator you want to insert by scanning a barcode (1 – 8) from
the Hex Numeric table in the back of this manual.
 Define the separator string using a sequence of four hex ascii codes from the table at the
back of this manual.
Example
: To define QTY/CODE separator =
: (colon)
Define QTY/CODE
separator
length Hex codes Text string
Read +
1
+
20 + 20 + 3A + 20
=
space space
: space
For more information on this feature see “Message Formatting” starting in par. 6.1 and 6.2.


Datalogic PowerScan D8300 Specifications

General

Brand	Datalogic
Model	PowerScan D8300
Category	Barcode Reader
Language	English
