Dell 2000FP LCD Monitor Service Guide
Alignment Procedure
Confidential
1
Casing input
LCM sorting
Use UXGA 60Hz with Full-White / Full-Black / Pure-R / Pure-G / Pure-B patterns to check LCM.
I/F board barcode scanning
Mechanical offset adjustment
DDC Programming
Preset timing check
D-SUB port / DVI port
Check the following preset timings with General pattern:
No. Mode H V
1 720×400 @ 70Hz 31.468 70.8
2 640×480 @ 60Hz 31.469 59.940
3 640×480 @ 75Hz 37.500 75.000
4 800×600 @ 60Hz 37.879 60.317
5 800×600 @ 75Hz 46.875 75.000
6 1024×768 @ 60Hz 48.363 60.004
7 1024×768 @ 75Hz 60.023 75.029
8 1280×1024 @ 60Hz 63.981 60.020
9 1280×1024 @ 75Hz 79.976 75.025
10 1600×1200 @ 60Hz 75.000 60.000
PIP function
No. Monitor settings Signal source Criteria
1 S-Video with DVD-NTSC
2
Main source: D-SUB or DVI displaying normally
PIP source: S-Video and PIP size: Large
S-Video with DVD-PAL
3 Comp. with DVD-NTSC
4
Main source: D-SUB or DVI displaying normally
PIP source: Comp. and PIP size: Large
Comp. with DVD-PAL
DVD video is displaying normally.
Video function
No. Monitor settings Signal source Criteria
1 S-Video with DVD-NTSC
2
Main source: S-Video
S-Video with DVD-PAL
3 Comp. with DVD-NTSC
4
Main source: Comp. video
Comp. with DVD-PAL
DVD video is displaying normally.
